Well NA03400906BAB
Unconfined



Home | Well Information | Hydrograph | Water Level Data Table
RGWCD Unconfined Wells:MapList
RGWCD Confined Wells:MapList
Baca Grant Wells:MapList
Divide Study Wells:MapList
Upper Rio Grande Wells:MapList
DWR Confined Wells:MapList
CWCD Wells:MapList
USBR Wells:MapList
USGS Wells:MapList
Dunes Hydro Study Wells:MapList
GSDNP Boundary Wells:MapList
Recently Monitored Wells:MapList
Unconfined Wells:MapList
Confined Wells:MapList

Index Map showing
model domain.

Green shaded area
enlarged below.

Click on map
to quickly move to
another location.


View Digital Orthophoto Quadrangle for this area

Well Information Table
Common Well IDNA03400906BAB
USGS Well ID371329106015401
USGS Station NameNA03400906BAB
USGS Site TypeWell
USGS Site Use InformationObservation
USGS Groundwater Use InformationUnused
Data Source(s)USGS
Location Data
TRSNA03400906BAB
USGS TRS 1NA03400906BAB
USGS TRSNWNENWS006T0034NR0009EN
Longitude/Latitude (NAD83)-106.03224700 , 37.22473116
Longitude/Latitude Data SourceGWSI decimal LAT/LONG field
USGS Longitude/Latitude (NAD83)-106.0322470 , 37.22473116
Easting, Northing RGDSS-NAD83 (US ft)95745.31 , 83512.13
USGS TopographyValley flat
USGS CountyConejos County
Elevation and Depth Data
Ground Elevation (ft NAVD88)7663.19
Elevation Data SourceUSGS GWSI database
USGS Ground Elevation (ft NGVD29)7659.00
1/3-Arc Second NED Ground Elevation (ft NAVD88)7678.48
1-Arc Second NED Ground Elevation (ft NAVD88)7677.74
SRTM Ground Elevation (ft NAVD88)7673.89
Total Depth (ft)29.00
USGS Well Depth (ft)29.00
Model Layer1
Model Layer SourceWell Depth
Depth of Bottom of Layer 126
Depth of Bottom of Layer 257
Depth of Bottom of Layer 3109
Depth of Bottom of Layer 4821
Additional Well InformationGeohydrology, Construction
Aquifer Information
Aquifer TypeUnconfined
Aquifer Type SourceTD Elevation/Model Layer
USGS Primary AquiferCenozoic Erathem
USGS Hydrologic UnitAlamosa-Trinchera
USGS Data AvailableWater-level (GW.LEV)
Water-level Database Information
Water-level Count31
Water-level Date Range09/05/1974 thru 05/03/1977
Monitored within the last 18 monthsNo, most recently on 05/03/1977
Depth-to-Water Range (ft)20.75 to 25.00
Water Table Elevation Range (ft NAVD88)7638.19 to 7642.44
Water-Level-Source:Number-of-MeasurementsUSGS:31

Top of Page


Water-level Data

1967 to Present

Top of Page


Measurement DateDepth to
Water (ft)
Elevation
(ft NAVD88)
Data
Source(s)
09/05/197424.007639.19USGS
10/05/197425.007638.19USGS
11/06/197424.167639.03USGS
12/04/197423.007640.19USGS
01/06/197522.417640.78USGS
02/05/197522.507640.69USGS
03/05/197522.167641.03USGS
04/07/197521.907641.29USGS
05/05/197523.407639.79USGS
06/05/197523.007640.19USGS
07/05/197521.587641.61USGS
09/07/197521.167642.03USGS
10/05/197521.167642.03USGS
11/05/197521.007642.19USGS
12/05/197521.167642.03USGS
01/05/197621.337641.86USGS
02/04/197623.837639.36USGS
03/15/197621.007642.19USGS
04/15/197621.837641.36USGS
05/15/197620.757642.44USGS
06/15/197621.007642.19USGS
07/15/197621.007642.19USGS
08/15/197622.757640.44USGS
09/03/197623.007640.19USGS
10/08/197622.667640.53USGS
11/05/197621.007642.19USGS
12/08/197620.837642.36USGS
02/05/197723.007640.19USGS
03/07/197722.257640.94USGS
05/01/197722.007641.19USGS
05/03/197722.407640.79USGS
