Well Information Table
Common Well IDNA03700826ABB DAVIS
USGS Well ID372522106032301
USGS Station NameNA03700826ABB DAVIS
USGS Site TypeWell
USGS Site Use InformationUnused
USGS Groundwater Use InformationUnknown
Data Source(s)USGS
Location Data
TRSNA03700826ABB DAVIS
USGS TRS 1NA03700826ABB DAVIS
Longitude/Latitude (NAD83)-106.05697070 , 37.42278267
Longitude/Latitude Data SourceGWSI decimal LAT/LONG field
USGS Longitude/Latitude (NAD83)-106.0569707 , 37.42278267
Easting, Northing RGDSS-NAD83 (US ft)88841.64 , 155632.94
USGS TopographyValley flat
USGS CountyRio Grande County
USGS Map NameWAVERLY
USGS Map Scale24000
Elevation and Depth Data
Ground Elevation (ft NAVD88)7629.22
Elevation Data SourceUSGS GWSI database
USGS Ground Elevation (ft NGVD29)7625.00
1/3-Arc Second NED Ground Elevation (ft NAVD88)7626.18
1-Arc Second NED Ground Elevation (ft NAVD88)7625.70
SRTM Ground Elevation (ft NAVD88)7627.90
Total Depth (ft)123.00
USGS Well Depth (ft)123.00
Model Layer2
Model Layer SourceWell Depth
Depth of Bottom of Layer 139
Depth of Bottom of Layer 2195
Depth of Bottom of Layer 3422
Depth of Bottom of Layer 42107
Additional Well InformationNONE
Aquifer Information
Aquifer TypeConfined
Aquifer Type SourceTD Elevation/Model Layer
USGS Hydrologic UnitAlamosa-Trinchera
USGS Data AvailableWater-level (GW.LEV)
Water-level Database Information
Water-level Count247
Water-level Date Range07/13/1983 thru 09/28/1987
Monitored within the last 18 monthsNo, most recently on 09/28/1987
Depth-to-Water Range (ft)5.75 to 8.67
Water Table Elevation Range (ft NAVD88)7620.55 to 7623.47
Water-Level-Source:Number-of-MeasurementsUSGS:247

Top of Page


Water-level Data

1967 to Present

Top of Page


Measurement DateDepth to
Water (ft)
Elevation
(ft NAVD88)
Data
Source(s)
07/13/19836.567622.66USGS
07/14/19836.677622.55USGS
07/21/19837.047622.18USGS
07/28/19836.227623.00USGS
08/01/19836.907622.32USGS
08/07/19836.847622.38USGS
08/14/19837.197622.03USGS
08/21/19837.797621.43USGS
08/28/19838.117621.11USGS
09/01/19838.237620.99USGS
09/07/19838.377620.85USGS
09/14/19838.477620.75USGS
09/21/19838.507620.72USGS
09/28/19838.377620.85USGS
10/01/19838.447620.78USGS
10/07/19838.567620.66USGS
10/14/19838.547620.68USGS
10/21/19838.277620.95USGS
10/28/19838.117621.11USGS
11/01/19838.277620.95USGS
11/07/19838.407620.82USGS
11/14/19838.487620.74USGS
11/21/19838.497620.73USGS
11/28/19838.537620.69USGS
12/01/19838.537620.69USGS
12/07/19838.537620.69USGS
12/14/19838.557620.67USGS
12/21/19838.607620.62USGS
12/28/19838.617620.61USGS
01/01/19848.627620.60USGS
01/07/19848.647620.58USGS
01/14/19848.657620.57USGS
01/21/19848.627620.60USGS
01/28/19848.657620.57USGS
02/01/19848.667620.56USGS
02/07/19848.667620.56USGS
02/14/19848.667620.56USGS
02/21/19848.677620.55USGS
02/28/19848.667620.56USGS
03/01/19848.657620.57USGS
03/07/19848.667620.56USGS
03/14/19848.557620.67USGS
03/21/19848.407620.82USGS
03/28/19848.367620.86USGS
04/01/19848.317620.91USGS
04/07/19848.277620.95USGS
04/14/19848.307620.92USGS
04/21/19848.267620.96USGS
04/28/19848.187621.04USGS
05/01/19848.157621.07USGS
05/07/19848.377620.85USGS
05/14/19848.397620.83USGS
05/21/19847.247621.98USGS
05/28/19847.537621.69USGS
06/01/19845.967623.26USGS
06/07/19845.977623.25USGS
07/28/19845.837623.39USGS
08/01/19846.697622.53USGS
08/07/19845.997623.23USGS
08/14/19845.907623.32USGS
08/21/19847.177622.05USGS
08/28/19847.637621.59USGS
09/01/19847.787621.44USGS
09/07/19848.007621.22USGS
09/14/19848.187621.04USGS
09/21/19847.687621.54USGS
09/28/19848.107621.12USGS
10/01/19848.167621.06USGS
10/07/19848.257620.97USGS
10/14/19848.327620.90USGS
10/21/19848.357620.87USGS
10/28/19848.357620.87USGS
11/01/19848.367620.86USGS
11/07/19848.367620.86USGS
11/14/19848.367620.86USGS
11/21/19848.377620.85USGS
11/28/19848.377620.85USGS
12/01/19848.377620.85USGS
12/07/19848.387620.84USGS
12/14/19848.427620.80USGS
12/21/19848.447620.78USGS
12/28/19848.437620.79USGS
01/01/19858.447620.78USGS
01/07/19858.467620.76USGS
01/14/19858.487620.74USGS
01/21/19858.517620.71USGS
01/28/19858.527620.70USGS
02/01/19858.527620.70USGS
02/07/19858.537620.69USGS
02/14/19858.567620.66USGS
02/21/19858.597620.63USGS
02/28/19858.557620.67USGS
03/01/19858.557620.67USGS
03/07/19858.507620.72USGS
03/14/19858.497620.73USGS
03/21/19858.487620.74USGS
03/28/19858.467620.76USGS
04/01/19858.397620.83USGS
04/07/19858.337620.89USGS
04/14/19858.287620.94USGS
04/21/19858.227621.00USGS
04/28/19858.347620.88USGS
05/01/19858.337620.89USGS
05/07/19858.367620.86USGS
05/14/19858.257620.97USGS
05/21/19858.097621.13USGS
05/28/19858.057621.17USGS
06/01/19858.107621.12USGS
06/07/19856.847622.38USGS
06/14/19856.937622.29USGS
06/21/19855.947623.28USGS
06/28/19856.877622.35USGS
07/01/19855.757623.47USGS
07/07/19856.357622.87USGS
07/14/19855.927623.30USGS
07/21/19856.047623.18USGS
07/28/19855.757623.47USGS
08/01/19856.427622.80USGS
08/07/19857.357621.87USGS
08/14/19857.677621.55USGS
08/21/19857.067622.16USGS
08/28/19857.797621.43USGS
09/01/19857.827621.40USGS
09/07/19857.857621.37USGS
09/14/19858.097621.13USGS
09/21/19858.217621.01USGS
09/28/19858.267620.96USGS
10/01/19858.297620.93USGS
10/07/19858.317620.91USGS
10/14/19858.317620.91USGS
10/21/19858.327620.90USGS
10/28/19858.347620.88USGS
11/01/19858.357620.87USGS
11/07/19858.347620.88USGS
11/14/19858.357620.87USGS
11/21/19858.357620.87USGS
11/28/19858.357620.87USGS
12/01/19858.347620.88USGS
12/07/19858.347620.88USGS
12/14/19858.337620.89USGS
12/21/19858.387620.84USGS
12/28/19858.417620.81USGS
01/01/19868.437620.79USGS
01/07/19868.447620.78USGS
01/14/19868.497620.73USGS
01/21/19868.487620.74USGS
01/28/19868.527620.70USGS
02/01/19868.537620.69USGS
02/07/19868.537620.69USGS
02/14/19868.517620.71USGS
02/21/19868.527620.70USGS
02/28/19868.507620.72USGS
03/01/19868.487620.74USGS
03/07/19868.417620.81USGS
03/14/19868.367620.86USGS
03/21/19868.257620.97USGS
03/28/19868.277620.95USGS
04/01/19868.287620.94USGS
04/07/19868.287620.94USGS
04/14/19868.297620.93USGS
04/21/19868.277620.95USGS
04/28/19868.307620.92USGS
05/01/19868.317620.91USGS
05/07/19867.997621.23USGS
05/14/19867.387621.84USGS
05/21/19866.837622.39USGS
05/28/19866.257622.97USGS
06/01/19866.747622.48USGS
06/07/19867.077622.15USGS
06/14/19867.087622.14USGS
06/21/19867.327621.90USGS
06/28/19866.957622.27USGS
07/01/19866.757622.47USGS
07/07/19866.987622.24USGS
07/14/19865.817623.41USGS
07/21/19867.187622.04USGS
07/28/19867.587621.64USGS
08/01/19867.627621.60USGS
08/07/19866.477622.75USGS
08/14/19866.957622.27USGS
08/21/19866.727622.50USGS
08/28/19866.507622.72USGS
09/01/19867.017622.21USGS
09/07/19867.657621.57USGS
09/14/19867.897621.33USGS
09/21/19868.067621.16USGS
09/28/19868.127621.10USGS
10/01/19868.157621.07USGS
10/07/19868.117621.11USGS
10/14/19868.137621.09USGS
10/21/19868.167621.06USGS
10/28/19868.177621.05USGS
11/01/19868.187621.04USGS
11/07/19868.057621.17USGS
11/14/19868.067621.16USGS
11/21/19868.097621.13USGS
11/28/19868.097621.13USGS
12/01/19868.097621.13USGS
12/07/19868.117621.11USGS
12/14/19868.147621.08USGS
12/21/19868.177621.05USGS
12/28/19868.217621.01USGS
01/01/19878.257620.97USGS
01/07/19878.307620.92USGS
01/14/19878.347620.88USGS
01/21/19878.337620.89USGS
01/28/19878.377620.85USGS
02/01/19878.407620.82USGS
02/07/19878.447620.78USGS
02/14/19878.437620.79USGS
02/21/19878.387620.84USGS
02/28/19878.327620.90USGS
03/01/19878.317620.91USGS
03/07/19878.287620.94USGS
03/14/19878.087621.14USGS
03/21/19878.067621.16USGS
03/28/19878.037621.19USGS
04/01/19877.997621.23USGS
04/07/19877.977621.25USGS
04/14/19877.957621.27USGS
04/21/19877.997621.23USGS
04/28/19878.087621.14USGS
05/01/19878.107621.12USGS
05/07/19878.127621.10USGS
05/14/19878.177621.05USGS
05/21/19878.077621.15USGS
05/28/19877.427621.80USGS
06/01/19877.657621.57USGS
06/07/19877.877621.35USGS
06/14/19877.377621.85USGS
06/21/19876.617622.61USGS
06/28/19876.497622.73USGS
07/01/19876.587622.64USGS
07/07/19877.307621.92USGS
07/14/19877.117622.11USGS
07/21/19876.327622.90USGS
07/28/19876.027623.20USGS
08/01/19876.277622.95USGS
08/07/19876.707622.52USGS
08/14/19877.067622.16USGS
08/21/19877.277621.95USGS
08/28/19877.197622.03USGS
09/01/19876.567622.66USGS
09/07/19877.517621.71USGS
09/14/19877.767621.46USGS
09/21/19877.967621.26USGS
09/28/19878.147621.08USGS
