| Well Information Table |
|---|
| Common Well ID | NA04200931CCC SAG 11 |
| RGWCD Confined Aquifer Well ID | SAG11 |
| USGS Well ID | 375009106021001 |
| USGS Station Name | NA04200931CCC SAG 11 |
| USGS Site Type | Well |
| USGS Site Use Information | Withdrawal of Water |
| USGS Groundwater Use Information | Unknown |
| Data Source(s) | USGS |
| Location Data |
|---|
| TRS | NA04200931CCC SAG 11 |
| USGS TRS 1 | NA04200931CCC SAG 11 |
| Longitude/Latitude (NAD83) | -106.03626218 , 37.83607728 |
| Longitude/Latitude Data Source | Davis Engineering Survey |
| USGS Longitude/Latitude (NAD83) | -106.0362500 , 37.83608330 |
| Easting, Northing RGDSS-NAD83 (US ft) | 95443.67 , 306059.42 |
| USGS County | Saguache County |
| USGS Map Name | CENTER NORTH |
| USGS Map Scale | 24000 |
| Elevation and Depth Data |
|---|
| Ground Elevation (ft NAVD88) | 7581.21 |
| Elevation Data Source | Davis Engineering Survey |
| USGS Ground Elevation (ft NAVD88) | 7581.21 |
| 1/3-Arc Second NED Ground Elevation (ft NAVD88) | 7581.53 |
| 1-Arc Second NED Ground Elevation (ft NAVD88) | 7581.33 |
| SRTM Ground Elevation (ft NAVD88) | 7590.08 |
| Total Depth (ft) | 1350.00 |
| USGS Well Depth (ft) | 1350.00 |
| Model Layer | 4 |
| Model Layer Source | Well Depth |
| Depth of Bottom of Layer 1 | 103 |
| Depth of Bottom of Layer 2 | 217 |
| Depth of Bottom of Layer 3 | 686 |
| Depth of Bottom of Layer 4 | 2436 |
| Additional Well Information | NONE |
| Aquifer Information |
|---|
| Aquifer Type | Confined |
| Aquifer Type Source | RGWCD_AQ |
| USGS Aquifer Type | Confined Single Aquifer |
| USGS Hydrologic Unit | Saguache |
| USGS Data Available | Water-level (GW.LEV) |
| Water-level Database Information |
|---|
| Water-level Count | 276 |
| Water-level Date Range | 04/15/1998 thru 04/23/2024 |
| Monitored within the last 18 months | Yes, most recently on 04/23/2024 |
| Depth-to-Water Range (ft) | -38.60 to -5.30 |
| Water Table Elevation Range (ft NAVD88) | 7586.51 to 7619.81 |
| Water-Level-Source:Number-of-Measurements | RGWCD:136 USGS:140 |
