Well DIV5111 | ||
Home | Well Information | Hydrograph | Water Level Data Table
|
Index Map showing model domain. Green shaded area Click on map |
Well Information Table | |
---|---|
Common Well ID | DIV5111 |
USGS Site Use Information | Unknown |
USGS Groundwater Use Information | Unknown |
Data Source(s) | Divide Study |
Location Data | |
Longitude/Latitude (NAD83) | -106.06957550 , 37.56724797 |
Longitude/Latitude Data Source | Divide Study |
Easting, Northing RGDSS-NAD83 (US ft) | 85405.26 , 208236.52 |
Elevation and Depth Data | |
Ground Elevation (ft NAVD88) | 7625.42 |
Elevation Data Source | Divide study surveying by Davis Engineering |
1/3-Arc Second NED Ground Elevation (ft NAVD88) | 7625.82 |
1-Arc Second NED Ground Elevation (ft NAVD88) | 7625.95 |
SRTM Ground Elevation (ft NAVD88) | 7641.38 |
Model Layer | 1 |
Model Layer Source | Aquifer Type |
Depth of Bottom of Layer 1 | 58 |
Depth of Bottom of Layer 2 | 164 |
Depth of Bottom of Layer 3 | 556 |
Depth of Bottom of Layer 4 | 2209 |
Additional Well Information | NONE |
Aquifer Information | |
Aquifer Type | Unconfined |
Aquifer Type Source | DIV_AQ |
Water-level Database Information | |
Water-level Count | 17 |
Water-level Date Range | 03/22/2007 thru 03/24/2023 |
Monitored within the last 18 months | No, most recently on 03/24/2023 |
Depth-to-Water Range (ft) | 12.42 to 14.83 |
Water Table Elevation Range (ft NAVD88) | 7610.59 to 7613.00 |
Water-Level-Source:Number-of-Measurements | Divide Study:17 |
